Integrated solution provider for air conditioning and refrigeration
1/2-5HP Mid & Low Temp Condensing Units
Feature: The condenser unit is compatible with mediumand low temperature evaporators. R404A/R454C ECO Friendly Refrigerant. Embraco/Invotech UL approved compressor. High and Low pressure protection, with fanrecycling function. Fan Blades: Specifically matched with motors andcoil for maximum air movement and cooling. Coil are constructed with copper tubes ancenhanced anti-corrosion aluminum fins. Other parts include suction accumulator, receiver,filter, sight glass, compressor heater Reserve defrost timer position. Painted galvanized steel housing against corrosion.
retail price：
market price：
Number：
Weight：
kg
remaining stock
隐藏域元素占位
- 产品描述
-
- Commodity name: 1/2-5HP Mid & Low Temp Condensing Units
Feature: The condenser unit is compatible with mediumand low temperature evaporators. R404A/R454C ECO Friendly Refrigerant. Embraco/Invotech UL approved compressor. High and Low pressure protection, with fanrecycling function. Fan Blades: Specifically matched with motors andcoil for maximum air movement and cooling. Coil are constructed with copper tubes ancenhanced anti-corrosion aluminum fins. Other parts include suction accumulator, receiver,filter, sight glass, compressor heater Reserve defrost timer position. Painted galvanized steel housing against corrosion.
Condensing Unit Models HP V-Ph-Hz Refrigerant Compressor Connections(Inch) Fan(s)Data Demension (W×D×H))inch Liquid Suction CFM No. KR055LC2H 1/4 208/230V,1Ph,60Hz R404A Embraco 3/8 1/2 241 1 14.76×19.49×11.02 KR075LC2H 3/4 3/8 1/2 382 1 15.75×20.08×12.01 KR103LC2H 1 3/8 1/2 824 1 25.47×27.24×18.98 KR126LC2H 1-1/2 3/8 1/2 1647 1 25.47×27.24×18.98 KS168LC2H 2 R454C Invotech 3/8 5/8 1647 1 25.47×27.24×18.98 KS212LC2H 2-1/2 3/8 5/8 1882 1 27.44×27.24×20.94 KS265LC2H 3 1/2 7/8 2353 2 36.89×27.24×18.98 KS308LC2H 3-1/2 1/2 7/8 3765 2 40.43×29.21×20.94 KS320LC2H 4 1/2 7/8 3765 2 42.40×29.92×26.85 KS398LC2H 5 1/2 7/8 3765 2 42.40×29.92×26.85 KS265LC3H 3 208/230V,3Ph,60Hz 1/2 7/8 2353 2 36.89×27.24×18.98 KS320LC3H 4 1/2 7/8 3765 2 42.40×29.92×26.85 KS398LC3H 5 1/2 7/8 3765 2 42.40×29.92×26.85
Previous page
Product Details
| Condensing Unit Models | HP | V-Ph-Hz | Refrigerant | Compressor | Connections(Inch) | Fan(s)Data | Demension (W×D×H))inch | ||
| Liquid | Suction | CFM | No. | ||||||
| KR055LC2H | 1/4 | 208/230V,1Ph,60Hz | R404A | Embraco | 3/8 | 1/2 | 241 | 1 | 14.76×19.49×11.02 |
| KR075LC2H | 3/4 | 3/8 | 1/2 | 382 | 1 | 15.75×20.08×12.01 | |||
| KR103LC2H | 1 | 3/8 | 1/2 | 824 | 1 | 25.47×27.24×18.98 | |||
| KR126LC2H | 1-1/2 | 3/8 | 1/2 | 1647 | 1 | 25.47×27.24×18.98 | |||
| KS168LC2H | 2 | R454C | Invotech | 3/8 | 5/8 | 1647 | 1 | 25.47×27.24×18.98 | |
| KS212LC2H | 2-1/2 | 3/8 | 5/8 | 1882 | 1 | 27.44×27.24×20.94 | |||
| KS265LC2H | 3 | 1/2 | 7/8 | 2353 | 2 | 36.89×27.24×18.98 | |||
| KS308LC2H | 3-1/2 | 1/2 | 7/8 | 3765 | 2 | 40.43×29.21×20.94 | |||
| KS320LC2H | 4 | 1/2 | 7/8 | 3765 | 2 | 42.40×29.92×26.85 | |||
| KS398LC2H | 5 | 1/2 | 7/8 | 3765 | 2 | 42.40×29.92×26.85 | |||
| KS265LC3H | 3 | 208/230V,3Ph,60Hz | 1/2 | 7/8 | 2353 | 2 | 36.89×27.24×18.98 | ||
| KS320LC3H | 4 | 1/2 | 7/8 | 3765 | 2 | 42.40×29.92×26.85 | |||
| KS398LC3H | 5 | 1/2 | 7/8 | 3765 | 2 | 42.40×29.92×26.85 | |||
